250克中小型注塑机液压系统设计【全套含CAD图纸】
收藏
资源目录
压缩包内文档预览：
编号：12541627
类型：共享资源
大小：1.33MB
格式：ZIP
上传时间：2019-01-02
上传人：机****料
认证信息
个人认证
高**（实名认证）
河南
IP属地：河南
50
积分
- 关 键 词：
-
全套含CAD图纸
中小型
注塑
液压
系统
设计
全套
cad
图纸
- 资源描述：
-
- 内容简介：
-
毕业设计（论文）任务书课题名称：250克中小型注塑机液压系统设计完成期限：2010年12月1日至 2011年5月25日院系名称专业班级学生姓名院系毕业设计（论文）工作领导小组组长签字 一、课题训练内容液压传动系统的作用是实现注塑机按工艺过程所要求的各种动作提供动力，并满足注塑机各部分所需压力、速度、温度等的要求。它主要由各自种液压元件和液压辅助元件所组成，其中油泵和电机是注塑机的动力来源。各种阀控制油液压力和流量，从而满足注射成型工艺各项要求。完成这一设计的重点是注塑成型、液力传动、液压伺服系统的原理和特点。本研究课题主要讨论如何设计注塑机液压控制系统，使其高效、准确、稳定、安全、可靠地运行。本设计主要有助于了解注塑机液压系统的特点与应用领域，液压系统的组成以及工作原理等。二、设计（论文）任务和要求（包括说明书、论文、译文、计算程序、图纸、作品等数量和质量等具体要求）设计任务和要求:1、了解注塑机和掌握注塑机的机械结构；2、注塑机液压系统功能分析；3、注塑机液压系统原理；4、掌握注塑机液压系统基本原理及其在工业中的应用；5、注塑机液压系统元件设计；6、学习和初步掌握产品设计的一般步骤和过程，为以后工作奠定一定的基础。其他论文格式方面的要求：a) 中文摘要一般在400字以内，但不得少于300字；b) 开题报告不少于2000字；c) 中英文摘要均要有关键词，一般为58个；d) 零号图纸不能少于一张，论文正文一般不少于10000字。e) 一篇英文文献翻译成中文,字数不少于3000字。三、毕业设计（论文）主要参数及主要参考资料250g塑料注射机液压系统设计参数如下：螺杆直径 40mm 螺杆行程 200mm 最大注射压力 153MPa 螺杆驱动功率 5kW 螺杆转速 60r/min 注射座行程 230mm 注射座最大推力 27kN 最大合模力(锁模力) 900kN 开模力 49kN 动模板最大行程 350mm 快速闭模速度 0.1m/s 慢速闭模速度 0.02m/s 快速开模速度 0.13m/s 慢速开模速度 0.03m/s 注射速度 0.07m/s 注射座前进速度 0.06m/s 注射座后移速度 0.08m/s主要参考资料：1 章宏甲，黄谊.液压传动M.机械工业出版社.2003 2 杨培元，朱福元.液压系统设计简明手册M.机械工业出版社.2004.7 3 雷天觉.液压工程手册M.北京：机械工业出版社.1990 4 马广，张国文.冲压与塑料成型机械M.山东科学技术出版社.2004.9 5 谢家瀛.组合机床设计简明手册M.北京：机械工业出版社.2002.86 李登万.液压与气压传动M.江苏: 东南大学出版社.20047 李胜海.液压机构及其组合M.北京: 清华大学出版社.19928金波，张佳林，顾临怡，李林.注塑机变量泵节能液压系统的AMESim仿真J.浙江大学.2010.49郑开陆.变量泵在大型注塑机液压伺服系统中的应用J.江汉大学.200610向鹏，李绣峰，杜遥雪.全电动注塑机的特点及应用领域J.五邑大学机电工程系.2007 11吴红，周骥平.小型注塑机液压驱动方式探讨J.扬州大学.200912徐宝林.一种大型注塑机控制系统的设计J.金羚电器有限公司.200513臧克江, 实用液压技术丛书M. 化学工业出版社,201014 杨培元，朱福元液压系统设计简明手册M. 机械工业出版社.200315 张利平.液压站设计与使用M. 北京：海洋出版社.2004.2 16 白柳. 液压与气压传动M. 机械工业出版社.2009四、毕业设计（论文）进度表武汉纺织大学毕业设计（论文）进度表序号起止日期计划完成内容实际完成情况检查人签名检查日期12010.12.1-2011.1.10针对所做课题，查阅相关资料，并撰写调研报告。 22011.1.10-2011.2.1仔细分析课题内容，准备开题报告一份，进行论文开题答辩，并针对答辩意见进行修改。32011.3.1-2011.3.10准备资料，掌握注塑机液压系统的结构和功能，以及其控制系统原理。42011.3.10-2011.4.10完成系统的原理图设计52011.3.10-2011.4.25完成参数分析设计62011.4.25-2011.5.10确定系统原理图及其元件选择，做出正确的液压系统。72011.5.10-2011.5.25对前期工作进行总结和归纳，撰写一份完整的毕业论文。82011.5.25-2011.5.27撰写毕业答辩文档， 92011.5.27-2011.5.28准备毕业答辩。250克中小型注塑机液压系统设计 机械专业中英文文献翻译英文原文Hydraulic SystemHydraulic presser drive and air pressure drive hydraulic fluid as the transmission is made according to the 17th century, Pascals principle of hydrostatic pressure to drive the development of an emerging technology, the United Kingdom in 1795 Braman Joseph (Joseph Braman ,1749-1814), in London water as a medium to form hydraulic press used in industry, the birth of the worlds first hydraulic press. Media work in 1905 will be replaced by oil-water and further improved.After the World War I (1914-1918) ,because of the extensive application of hydraulic transmission, espec- ially after 1920, more rapid development. Hydraulic components in the late 19th century about the early 20th century, 20 years, only started to enter the formal phase of industrial production. 1925 Vickers (F. Vikers) the invention of the pressure balanced vane pump, hydraulic components for the modern industrial or hydraulic transmission of the gradual establishment of the foundation. The early 20th century G Constantimscofluct- uations of the energy carried out by passing theoretical and practical research; in 1910 on the hydraulic trans- mission (hydraulic coupling, hydraulic torque converter, etc.) contributions, so that these two areas of develo- pment.The Second World War (1941-1945) period, in the United States 30% of machine tool applications in the hydraulic transmission. It should be noted that the development of hydraulic transmission in Japan than Europe and the United States and other countries for nearly 20 years later. Before and after in 1955, the rapid development of Japans hydraulic drive, set up in 1956, Hydraulic Industry. Nearly 20 to 30 years, the development of Japans fast hydraulic transmission, a world leader.Hydraulic transmission There are many outstanding advantages, it is widely used, such as general industr- ial use of plastics processing machinery, the pressure of machinery, machine tools, etc.; operating machinery engineering machinery, construction machinery, agricultural machinery, automobiles, etc.; iron and steel indu- stry metallurgical machinery, lifting equipment, such as roller adjustment device; civil water projects with flo- od control and dam gate devices, bed lifts installations, bridges and other manipulation of institutions; speed turbine power plant installations, nuclear power plants, etc.; ship from the deck heavy machinery (winch), the bow doors, bulkhead valve, stern thruster, etc.; special antenna technology giant with control devices, measu- rement buoys, movements such as rotating stage; military-industrial control devices used in artillery, ship anti- rolling devices, aircraft simulation, aircraft retractable landing gear and rudder control devices and other devi- ces.A complete hydraulic system consists of five parts, namely, power components, the implementation of co- mponents, control components, auxiliary components and hydraulic oil. The role of dynamic components of the original motive fluid into mechanical energy to the pressure that the hydraulic system of pumps, it is to power the entire hydraulic system. The structure of the form of hydra- ulic pump gears are generally pump, vane pump and piston pump. Implementation of components (such as hydraulic cylinders and hydraulic motors) which is the pressure of the liquid can be converted to mechanical energy to drive the load for a straight line reciprocating movement or rotational movement. Control components (that is, the various hydraulic valves) in the hydraulic system to control and regulate the pressure of liquid, flow rate and direction. According to the different control functions, hydraulic pressure control valve can be divided into valves, flow control valves and directional control valve. Pressure control valves are divided into benefits flow valve (safety valve), pressure relief valve, sequence valve, pressure relays, etc.; flow control valves including throttle, adjusting the valves, flow diversion valve sets, etc.; directional control valve includes a one-way valve , one-way fluid control valve, shuttle valve, valve and so on. Under the control of different ways, can be divided into the hydraulic valve control switch valve, control valve and set the value of the ratio control valve. Auxiliary components, including fuel tanks, oil filters, tubing and pipe joints, seals, pressure gauge, oil level, such as oil dollars. Hydraulic oil in the hydraulic system is the work of the energy transfer medium, there are a variety of mineral oil, emulsion oil hydraulic molding Hop categories. The role of the hydraulic system is to help humanity work. Mainly by the implementation of components to rotate or pressure into a reciprocating motion. Hydraulic system and hydraulic power control signal is composed of two parts, the signal control of some parts of the hydraulic power used to drive the control valve movement. Part of the hydraulic power means that the circuit diagram used to show the different functions of the interrelationship between components. Containing the source of hydraulic pump, hydraulic motor and auxiliary components; hydraulic control part contains a variety of control valves, used to control the flow of oil, pressure and direction; operative or hydraulic cylinder with hydraulic motors, according to the actual requirements of their choice.In the analysis and design of the actual task, the general block diagram shows the actual operation of equi - pment. Hollow arrow indicates the signal flow, while the solid arrows that energy flow. Basic hydraulic circuit of the action sequence - Control components (two four-way valve) and the spring to reset for the implementation of components (double-acting hydraulic cylinder), as well as the extending and retracting the relief valve opened and closed . For the implementation of components and control components, presentations are based on the corresponding circuit diagram symbols, it also introduced ready made circuit diagram symbols. Working principle of the system, you can turn on all circuits to code. If the first implementation of components numbered 0, the control components associated with the identifier is 1. Out with the implementation of components corresponding to the identifier for the even components, then retracting and implementation of components corresponding to the identifier for the odd components. Hydraulic circuit carried out not only to deal with numbers, but also to deal with the actual device ID, in order to detect system failures.DIN ISO1219-2 standard definition of the number of component composition, which includes the following four parts: device ID, circuit ID, component ID and component ID. The entire system if only one device, device number may be omitted. Practice, another way is to code all of the hydraulic system components for numbers at this time, components and component code should be consistent with the list of numbers. This method is particularly applicable to complex hydraulic control system, each control loop are the corresponding number with the systemWith mechanical transmission, electrical transmission compared to the hydraulic drive has the following advantages: 1, a variety of hydraulic components, can easily and flexibly to layout. 2, light weight, small size, small inertia, fast response. 3, to facilitate manipulation of control, enabling a wide range of stepless speed regulation (speed range of 2000:1). 4, to achieve overload protection automatically. 5, the general use of mineral oil as a working medium, the relative motion can be self-lubricating surface, long service life; 6, it is easy to achieve linear motion / 7, it is easy to achieve the automation of machines, when the joint control of the use of electro-hydraulic, not only can achieve a higher degree of process automation, and remote control can be achieved. The shortcomings of the hydraulic system: 1, as a result of the resistance to fluid flow and leakage of the larger, so less efficient. If not handled properly, leakage is not only contaminated sites, but also may cause fire and explosion. 2, vulnerable performance as a result of the impact of temperature change, it would be inappropriate in the high or low temperature conditions. 3, the manufacture of precision hydraulic components require a higher, more expensive and hence the price. 4, due to the leakage of liquid medium and the compressibility and can not be strictly the transmission ratio. 5, hydraulic transmission is not easy to find out the reasons for failure; the use and maintenance requirements for a higher level of technology.In the hydraulic system and its system, the sealing device to prevent leakage of the work of media within and outside the dust and the intrusion of foreign bodies. Seals played the role of components, namely seals. Medium will result in leakage of waste, pollution and environmental machinery and even give rise to malfunctioning machinery and equipment for personal accident. Leakage within the hydraulic system will cause a sharp drop in volumetric efficiency, amounting to less than the required pressure, can not even work. Micro-invasive system of dust particles, can cause or exacerbate friction hydraulic component wear, and further lead to leakage. Therefore, seals and sealing device is an important hydraulic equipment components. The reliability of its work and life, is a measure of the hydraulic system an important indicator of good or bad. In addition to the closed space, are the use of seals, so that two adjacent coupling surface of the gap between the need to control the liquid can be sealed following the smallest gap. In the contact seal, pressed into self-seal-style and self-styled self-tight seal (ie, sealed lips) two.The three hydraulic system diseases 1, as a result of heat transmission medium (hydraulic oil) in the flow velocity in various parts of the existence of different, resulting in the existence of a liquid within the internal friction of liquids and pipelines at the sam- e time there is friction between the inner wall, which are a result of hydraulic the reasons for the oil tempera- ture. Temperature will lead to increased internal and external leakage, reducing its mechanical efficiency. At the same time as a result of high temperature, hydraulic oil expansion will occur, resulting in increased com- pression, so that action can not be very good control of transmission. Solution: heat is the inherent characte -ristics of the hydraulic system, not only to minimize eradication. Use a good quality hydraulic oil, hydraulic piping arrangement should be avoided as far as possible the emergence of bend, the use of high-quality pipe and fittings, hydraulic valves, etc.2, the vibration of the vibration of the hydraulic system is also one of its malaise. As a result of hydraulic oil in the pipeline flow of high-speed impact and the control valve to open the closure of the impact of the process are the reasons for the vibration system. Strong vibration control action will cause the system to error, the system will also be some of the more sophisticated equipment error, resulting in system failures. Solutions: hydraulic pipe should be fixed to avoid sharp bends. To avoid frequent changes in flow direction, can not avoid damping measures should be doing a good job. The entire hydraulic system should have a good damping measures, while avoiding the external local oscillator on the system.3, the leakage of the hydraulic system leak into inside and outside the leakage leakage. Leakage refers to the process with the leak occurred in the system, such as hydraulic piston-cylinder on both sides of the leakage, the control valve spool and valve body, such as between the leakage. Although no internal leakage of hydra- ulic fluid loss, but due to leakage, the control of the established movements may be affected until the cause system failures. Outside means the occurrence of leakage in the system and the leakage between the external environment. Direct leakage of hydraulic oil into the environment, in addition to the system will affect the working environment, not enough pressure will cause the system to trigger a fault. Leakage into the enviro- nment of the hydraulic oil was also the danger of fire. Solution: the use of better quality seals to improve the machining accuracy of equipment. Another: the hydraulic system for the three diseases, it was summed up: fever, with a father拉稀 (This is the summary of the northeast people). Hydraulic system for the lifts, excavators, pumping station, dynamic, crane, and so on large-scale industry, construction, factories, enterprises, as well as elevators, lifting platforms, Deng Axle industry and so on. Hydraulic components will be high-performance, high-quality, high reliability, the system sets the direction of development; to the low power, low noise, vibration, without leakage, as well as pollution control, water-based media applications to adapt to environmental requirements, such as the direction of development; the development of highly integrated high power density, intelligence, mechatronics and micro-light mini-hydraulic components; active use of new techniques, new materials and electronics, sensing and other high-tech.- Hydraulic coupling to high-speed high-power and integrated development of hydraulic transmission equ- ipment, development of water hydraulic coupling medium speed and the field of automotive applications to develop hydraulic reducer, improve product reliability and working hours MTBF; hydraulic torque converter to the development of high-power products, parts and components to improve the manufacturing process tech -nology to improve reliability, promote computer-aided technology, the development of hydraulic torque con- verter and power shift transmission technology supporting the use of ; Clutch fluid viscosity should increase the quality of products, the formation of bulk to the high-power and high-speed direction. Pneumatic Industry:- Products to small size, light weight, low power consumption, integrated portfolio of development, the implementation of the various types of components, compact structure, high positioning accuracy of the direction of development; pneumatic components and electronic technology, to the intelligent direction of development; component performance to high-speed, high-frequency, high-response, high-life, high temp- erature, high voltage direction, commonly used oil-free lubrication, application of new technology, new technology and new materials.(1) used high-pressure hydraulic components and the pressure of continuous work to reach 40Mpa, the maximum pressure to achieve instant 48Mpa; (2) diversification of regulation and control; (3) to further improve the regulation performance, increase the efficiency of the powertrain; (4) development and mechanical, hydraulic, power transmission of the composite portfolio adjustment gear; (5) development of energy saving, energy efficient system function; (6) to further reduce the noise; (7) Application of Hydraulic Cartridge Valves thread technology, compact structure, to reduce the oil spill.中文译文液压系统液压传动和气压传动称为流体传动，是根据17世纪帕斯卡提出的液体静压力传动原理而发展起来的一门新兴技术，1795年英国约瑟夫布拉曼(Joseph Braman,1749-1814)，在伦敦用水作为工作介质，以水压机的形式将其应用于工业上，诞生了世界上第一台水压机。1905年将工作介质水改为油，又进一步得到改善。第一次世界大战(1914-1918)后液压传动广泛应用，特别是1920年以后，发展更为迅速。液压元件大约在 19 世纪末 20 世纪初的20年间，才开始进入正规的工业生产阶段。1925 年维克斯(F.Vikers)发明了压力平衡式叶片泵,为近代液压元件工业或液压传动的逐步建立奠定了基础。20 世纪初康斯坦丁尼斯克对能量波动传递所进行的理论及实际研究;1910年对液力传动(液力联轴节、液力变矩器等)方面的贡献，使这两方面领域得到了发展。第二次世界大战(1941-1945)期间,在美国机床中有30%应用了液压传动。应该指出,日本液压传动的发展较欧美等国家晚了近 20 多年。在 1955 年前后 , 日本迅速发展液压传动,1956 年成立了“液压工业会”。近2030 年间，日本液压传动发展之快，居世界领先地位。液压传动有许多突出的优点，因此它的应用非常广泛，如一般工业用的塑料加工机械、压力机械、机床等；行走机械中的工程机械、建筑机械、农业机械、汽车等；钢铁工业用的冶金机械、提升装置、轧辊调整装置等；土木水利工程用的防洪闸门及堤坝装置、河床升降装置、桥梁操纵机构等；发电厂涡轮机调速装置、核发电厂等等；船舶用的甲板起重机械（绞车）、船头门、舱壁阀、船尾推进器等；特殊技术用的巨型天线控制装置、测量浮标、升降旋转舞台等；军事工业用的火炮操纵装置、船舶减摇装置、飞行器仿真、飞机起落架的收放装置和方向舵控制装置等。一个完整的液压系统由五个部分组成，即动力元件、执行元件、控制元件、辅助元件和液压油。 动力元件的作用是将原动机的机械能转换成液体的压力能，指液压系统中的油泵，它向整个液压系统提供动力。液压泵的结构形式一般有齿轮泵、叶片泵和柱塞泵。 执行元件(如液压缸和液压马达)的作用是将液体的压力能转换为机械能，驱动负载作直线往复运动或回转运动。 控制元件(即各种液压阀)在液压系统中控制和调节液体的压力、流量和方向。根据控制功能的不同，液压阀可分为压力控制阀、流量控制阀和方向控制阀。压力控制阀又分为益流阀(安全阀)、减压阀、顺序阀、压力继电器等；流量控制阀包括节流阀、调整阀、分流集流阀等；方向控制阀包括单向阀、液控单向阀、梭阀、换向阀等。根据控制方式不同，液压阀可分为开关式控制阀、定值控制阀和比例控制阀。 辅助元件包括油箱、滤油器、油管及管接头、密封圈、压力表、油位油温计等。 液压油是液压系统中传递能量的工作介质，有各种矿物油、乳化液和合成型液压油等几大类。 液压系统的作用就是帮助人类做工。主要是由执行元件把压力变成转动或往复运动。 液压系统由信号控制和液压动力两部分组成，信号控制部分用于驱动液压动力部分中的控制阀动作。液压动力部分采用回路图方式表示，以表明不同功能元件之间的相互关系。液压源含有液压泵、电动机和液压辅助元件；液压控制部分含有各种控制阀，其用于控制工作油液的流量、压力和方向；执行部分含有液压缸或液压马达，其可按实际要求来选择。在分析和设计实际任务时，一般采用方框图显示设备中实际运行状况。 空心箭头表示信号流，而实心箭头则表示能量流。基本液压回路中的动作顺序控制元件（二位四通换向阀）的换向和弹簧复位、执行元件（双作用液压缸）的伸出和回缩以及溢流阀的开启和关闭。 对于执行元件和控制元件，演示文稿都是基于相应回路图符号，这也为介绍回路图符号作了准备。根据系统工作原理，您可对所有回路依次进行编号。如果第一个执行元件编号为0，则与其相关的控制元件标识符则为1。如果与执行元件伸出相对应的元件标识符为偶数，则与执行元件回缩相对应的元件标识符则为奇数。 不仅应对液压回路进行编号，也应对实际设备进行编号，以便发现系统故障。DIN ISO1219-2标准定义了元件的编号组成，其包括下面四个部分：设备编号、回路编号、元件标识符和元件编号。如果整个系统仅有一种设备，则可省略设备编号。实际中，另一种编号方式就是对液压系统中所有元件进行连续编号，此时，元件编号应该与元件列表中编号相一致
