- 关 键 词：
-
含CAD图纸、说明书
四辊卷板机设计
四辊卷板机设计【
卷板机设计【4
四辊卷板机设计说明书
含CAD图纸】
四辊卷板机设计【CAD图纸
含CAD图纸
CAD图纸设计
- 资源描述：
-
- 内容简介：
-
附录：外文资料和中文翻译外文资料：Testing of Tool Life CostMachining cost is the sum of the machine tool cost and the cutter cost. The machine cost consists of idle cost, machining cost, and tool changing cost. The machining cost decreases with increased cutting speed; while the idle cost remains constant with changes in cutting speed. From the machining data handbook 24 the generalized machining cost equation is listed below: In order to optimize the cutting condition, it is essential to determine the mathematical relationship between the cuttings inserts type and cutting speed. In our study Taylors model will be used in relating the cutting tool life to the cutting speed:VT =C V= cutting speedT= Cutting time to produce a standard amount of flank wear (e.g. 0.2mm) n and C are constants for the material or conditions used.In order to determine constants n and C for the cutting inserts under study in machining 4140 steel and the conditions used in the experiments, a LogV against LogT is drawn and shown for the three types of cutting inserts under study Figure 1, Figure 2are for KC313 under dry and wet conditions, Figure 3, and Figure 4are for KC732. In addition, Figure 6, and Figure 7are for KC5010. It can be seen from the aforementioned figures that in-spite of considerable scatter in test measurements, the results fall reasonably well on a straight line. From the curves it can be seen that for the same cutting speed the tool life increases by increasing the wear criterion and introduction of coolant emulsion for KC313 and KC732. However, as seen in KC5010 tool life increases by increasing the wear criterion and decreases by introducing coolant. This negative behavior of KC5010 toward coolant emulsion and the effect of wear mechanisms behind it will be covered in Chapter 5. As well as the wear kinds on other inserts investigated in this research.Metal cutting studies focused on tools wear, tool life, and wear mechanisms. However, future research should pay more attention to other factors as well:l Wear criterion value set up by the factory system, which basically the tool wear threshold value that suits the factory product.l Types of tools used, such as carbide tips and high speed tools. Studying the variation of tool life wear under dry and wet cutting that effect the tool life equation constants (C,n) is useful. This will improve tool life because it also affects the economy of cutting 24.In order to determine the effect of cutting fluid on the selected wear criterion, relationship between different wear criteria and machining cost for the cutting inserts under HSM must be studied. The value of the tool life constants (C,n) for different wear criteria are extracted and plotted within the ranges listed in table (1). The values of the constants (C, n) extracted from Figure 1/B, Figure 3IB, and Figure 3-10 are shown in tables1 and 2. Further explanation of the relationship between these parameters and wear criteria will be covered through out the next figures. Figure5represents the relationship between n and wear criterion. As wear criterion increase n.(a) Log (time) versus Log (speed) at different wear criteria (dry condition).(b) Log (time) versus Log (speed) at different wear criteria (wet condition)Figure 2Time versus speed at different wear criteria KC313. (a) Log (time) versus Log (speed) at different wear criteri(drycondition). (b) Log (time) versus Log (speed) at different wear criteria (wet condition).(a) Log (time) versus Log (speed) at different wear criteria (dry condition)(b) Log (time) versus Log (speed) at different wear criteria (wet condition).Figure 3Time versus speed at different wear criteria KC732 (a)Log (time) versus Log(speed) at different wear criteria (dry condition), (b) Log (time) versus Log (speed) at different wear criteria (wet condition)(a) Log (time) versus Log (speed) at different wear criteria (dry condition).(b) Log (time) versus Log (speed) at different wear criteria (wet condition)Figure 3-10 Time versus speed at different wear criteria KC5010 (a) Log (time) versus Log(speed) at different wear criteria (dry condition), (b) Log (time) versus Log (speed) at different wear criteria (wet condition).Table 1 Ranges of plotted tool life constants.RangeCutting InsertCondition0 LogT 2.6KC313Dry0 Log T 4.1KC313Wet0 LogT 2.6KC5010Dry0 Log T 1.75KC5010Wet0 LogT 2.1KC732Dry0 Log T 2.4KC732WetTable 2 Wear Criteria versus C and n for three cutting inserts (Dry Condition).WearCriteria(mm)KC 313KC 5010KC732CnCnCnconstantconstantconstantconstantconstantconstant0.151420.2605180.2486300.2880.21650.2125600.2649640.3640.251960.2405960.27810990.3710.32380.2936050.27912330.3930.352500.2756120.27913990.4210.42630.2816250.28115030.4340.452820.2926250.27815170.4340.52920.2946300.27615770.4420.553020.2966320.27415920.4430.63130.3006380.27416110.444Table 3Wear Criteria versus C and n for three cutting inserts (Wet Condition).KC 313KC 5010KC732Wear criterion(mm)CnCnCn0.151670.2014970.298881.0500.3320.21870.2106190.3101051.960.3530.252280.2406100.3121297.180.39300.32440.2506280.3091545.250.42400.352670.2606260.3001782.380.45400.42910.2806190.2901918.670.46800.453380.3106150.2822137.960.49100.53030.3106160.279 2477.420.52400.553970.3406180.2782837.920.55400.64220.3506260.2793243.390.5830values increase for both cutting conditions. In addition, n values for wet condition is lower than dry conditions up until wear criterion 0.38 after which n for wet starts to get bigger. Figure 5 shows C values versus wear criterion, and reveals C increases as the wear criterion increases for both dry and wet cutting. However, C values under wet condition are getting higher than under dry conditions. This proves the increase in tool life by introducing coolant emulsion and by increasing the wear criterion for this cutting tool material during cutting.Next, Figure 6represents values of n with respect to wear criterion for KC732 material under dry and wet conditions. As the wear criteria increase n values increase. Furthermore, wear curve is higher than dry curve. Figure7 presents a proportional relationship between constant C values and wear criterion. However, wet C curve is higher than dry curves, which indicates the benefit of using coolant emulsion for material KC732. This benefit becomes more essential by increasing the wear criterion. The higher the C value; the higher the tool life becomes. Figure8shows the effect of introducing coolant emulsion on cutting tool performance. Therefore, the higher n; the lower the tool life is. Figure9shows the drop in C values by increasing the wear criterion and coolant usage; thus indicating a shorter tool life in wet cutting condition. During the previous curves of KC313 and KC732 materials, the increase in n values was an indication off shortened tool life. However, the huge increase in wet C curves over dry C over compensated the drop and elongated tool life for KC313 and KC732. In contrast, the case is for KC5010. Figure 12 and Figure 10 are for uncoated cemented carbide (KC313). It shows the relationship between cost cutting speeds for different wear criteria under dry and wet cutting.(a) n values versus wear criterion (wet and dry).(b) C values versus wear criterion (wet and dry).Figure 11Taylors constants for KC313 versus wear criteria,(a) n values versus wear criteria (wet and dry), (b) C values versus wear criteria (wet and dry).(a) n values versus wear criterion (wet and dry).(b) C values versus wear criterion (wet and dry).Figure 12Taylors constants for KC732 versus wear criteria, (a) n values versus wear criteria (wet and dry), (b) C values versus wear criteria (wet and dry).(a) n values versus wear criterion (wet and dry). (b) C values versus wear criterion (wet and dry)Figure 13 Taylors constants for KC5010 versus wear criteria, (a) n values versus wear criteria (wet and dry), (b) C values versus wear criteria (wet and dry).Both conditions indicate as the wear criteria increases the machining cost decreases. Nonetheless, as the speed increases the cost reaches optimum value and then increases. Figure 14 and Figure 3-15B show economical comparison between dry and wet cutting at (0.4 and 0.6 mm) wear criterion. Optimum cutting speed for dry cutting is 90 m/min while 120 m/min is for wet cutting.Cost as a function of speed is presented in Figure15 and Figure 16 for sandwich coating (KC732) under dry and wet conditions. Again, as wear criteria increases, cost decreases. Furthermore, the optimum speed of 260 m/min of dry cutting, increased to 360 m/min in cases of wet cutting. This indicates the importance of coolant with this material not only decreases cost but also increases productivity.Figure 3-17A and Figure 17 summarize the relationship of cost and speed for coated tools with TiALN (KC5010) under dry and wet cutting conditions. As the cutting speed increases the cost increases and as the wear criteria increases the cost decreases. The optimum cost was at the lowest speed (210 m/min) in both machining conditions.A cost comparison between KC732 and KC5010 at different wear criteria and machining conditions is presented in Figures 18 and19. It can be seen that KC732 responded positively to coolant in terms of extended tool life, and increased the optimum cutting speed from 260m/min to 360 nn/min. Nonetheless, coolant introduction to KC5010 at high speed cutting lowered the tool life and increased machining cost. The data presented in the aforementioned figures shows that dry cutting is more cost effective than wet cutting within speed range of 210 m/min-310 m/min for KC732 and vise versa at any speed higher than 310m/min. Cutting tool material KC5010 is cost effective at dry and 210 m/min. Therefore, in spite of the cost of the KC732; it is proven to be superior over KC313 (uncoated) and KC5010 in wear cost. Table 3 summarizes the optimum values of cost and speed under wet and dry cutting.Figures18, and 17for KC313 (uncoated) show the relationship between costs and wear criterion at different cutting speeds under dry and wet conditions. Figure 20, and Figure 21 are plotted for KC732 presenting cutting cost as a function of wear criteria for dry and wet conditions. Figure 3-21A and Figure 3-21B are plotted for KC5010. The curves show that for the same cutting velocity, by increases the selected wear criterion, the cost decreases.The improved performance of (KC313) under wet over dry cutting in terms off tool life is presented in Figure 22. The results of the two coatings testing methods, of flank wear for the KC732 and KC5010 are shown in Figure 23. Clearly this indicates improvement in cutting inserts life with TiN-TiCN-TiN coatings (KC732) under wet over dry cutting, and reduction in tool life of TiALN coating (KC5010) on wet cutting. Finally, KC732 provides superior performance under all cutting conditions over KC5010.(a) The variation of cost versus cutting speed at different wear criteria (dry ).(b) The variation of cost versus cutting speed at different wear criteria (wet).Figure 23 Cost variation with speed for KC313, (a) The variation of cost versus cutting speed at different wear criteria (dry), (b) The variation of cost versus cutting speed at different wear criteria (wet).(a) The variation of cost versus cutting speed at 0.4mm wear criterion. (b) The variation of cost versus cutting speed at 0.6mm wear criterionFigure 24 Cost versus speed comparison at wet and dry at two values of wear Criterion: (a) The variation of cost versus cutting speed at 0.4mm wear Criterion, (b) The variation of cost versus cutting speed at 0.6mm wear criterion.(a) The variation of cost versus cutting speed at different wear criteria (dry ). (b) The variation of cost versus cutting speed at different wear criteria (wet).Figure 25 Cost variation with speed for KC732, (a) The variation of cost versus cutting speed at different wear criteria (dry), (b) The variation of cost versus cutting speed at different wear criteria (wet).(a) The variation of cost versus cutting speed at different wear criteria (dry ).(b) The variation of cost versus cutting speed at different wear criteria (wet).Figure 26 Cost variation with speed for KC732, (a) The variation of cost versus cutting speed at different wear criteria (dry), (b) The variation of cost versus cutting speed at different wear criteria (wet).(a) Cost versus speed at 0.4 mm wear criterion(b) Cost versus speed at 0.6 mm wear criterionFigure 27 Cost comparison between KC5010 and KC732 at different wear criteria (a) Cost versus speed at 0.4 mm wear criterion, (b) Cost versus speed at 0.6 mm wear criterion.Table4 Comparison between three cutting inserts at the same wear criterion Tool TypeWear criterion(mm)Optimum Cost/ Speed(m/min)DryWetKC3130.647$ /9040$/90KC50100.634$ /21036$/210KC7320.629$ /26028.84$/360(a) The variation of cost versus wear criterion at different cutting speeds (dry ).(b) The variation of cost versus cutting speed at different wear criteria (wet).Figure 26 Cost variation with wear criteria for KC313, (a): The variation of cost versus cutting speed at different wear criteria (dry), (b): The variation of cost versus cutting speed at different wear criteria (wet).（a）The variation of cost versus wear criterion at different cutting speeds (dry )(b)The variation of cost versus wear criterion at different cutting speeds (wet).Figure 3-20 Cost variation with wear criteria for KC732, (a): The variation of cost versus cutting speed at different wear criteria (dry), (b): The variation of cost versus cutting speed at different wear criteria (wet).(a) The variation of cost versus wear criterion at different cutting speeds (dry ).(b) The variation of cost versus wear criterion at different cutting speeds (wet).Figure 3-21 Cost variation with wear criteria for KC5010, (a) The variation of cost versus cutting speed at different wear criteria (dry), (b) The variation of cost versus cutting speed at different wear criteria (wet)(a) Tool life at 0.4 mm wear criterion for KC313 (dry & wet).(b)Tool life at 0.4 mm wear criterion of KC732 and KC5010 (dry &wet). Figure 3-22 Tool life comparison at 0.4 wear criterion under dry and wet(a) Tool life at 0.4 mm wear criterion for KC313 (dry & wet), (b) Tool life at 0.4 mm wear criterion of KC732 and KC5010 (dry &wet).The cutting inserts were retested at cutting speed values within the range of experimental testing speeds under dry and wet machining condition. The results presented are for the cemented carbide uncoated (KC313), cemented carbide coated with TiALN (KC5010), and for the KC732. Figures 3-23A and 3-23B show the theoretical and experimental results of machining KC313 at a cutting speed of 100 m/min, and 160 m/min respectively. A good agreement between theoretical and experimental values was noticed indicating the accuracy of Taylors formula in predicting the tool life. Figures 3-24A and 3-24B present theoretical and experimental results of machining KC5010, at two different cutting speeds 280 m/min and 390 m/min good agreement between both was noticed. Experimental and theoretical data for the KC732 are presented in Figures 3-25A, and 3-25B under 280m/min and 390m/min. In this section result samples were presented and the rest of figures are included in the appendix.(a) Theoretical and experimental results of machining KC313 at 100m/min.(b) Theoretical and experimental results of machining KC313 at 160m/min.Figure 3-23 Theoretical and experimental results for KC313 under wet and dry cutting at different speeds: (a) Theoretical and experimental results of machining KC313 at 100m/min, (b) Theoretical and experimental results of machining KC313 at 160m/min.(a) Theoretical and experimental results of machining KC5010 at 280m/min.(b) Theoretical and experimental results of machining KC5010 at 390m/min.Figure 3-24 Theoretical and experimental results for KC5010 under wet and dry cutting at different speeds: (a) Theoretical and experimental results of machining KC5010 at 280m/min, (b) Theoretical and experimental results of machining KC5010 at 390m/min.(a) Theoretical and experimental results of machining KC732 at 280m/min.(b) Theoretical and experimental results of machining KC732 at 390m/min.Figure 3-25 Theoretical and experimental results for KC732 under wet and dry cutting at different speeds: (a) Theoretical and experimental results of machining KC732 at 280m/min, (b)Theoretical and experimental results of machining KC732 at 390m/min.中文翻译：刀具成本的检测加工成本是加工工具成本和切削成本的总和。机床成本由闲置费用，加工费用和工具改变费用组成。当改变切削速度的情况下闲置费用保持不变。从机械数据手册24上表明机械设备成本的公式如下：Error! No bookmark name given.为了优化切割条件,必须确定切割深度大小和切割速度的数学关系式.在 我们学习的泰勒模型将被用于确定切削速度对切削刀具寿命的影响:VT =C -3-2V=切削速度T=切割时产生的标准金额侧翼磨损(例如.0.2毫米)N和C都是由被使用的材料或者工作条件所决定的常数. ,为了确定进给时的常数n和C我们以4140钢在实验的条件下进行研究，以LogV和LogT为坐标进行作图，画出了三种类型的进给图形，图1、图2是对KC313为研究对象在干和湿的条件下分别做出的图形，图3和图4是对KC732为研究对象在干和湿两种状态下所做的图形，另外,图5、图6是以KC5010为研究对象在干和湿两种状况下所做的图形. 从上述的图形可以看出不管测量的次数有多少,其结果都是呈直线分布的形式下降,从曲线我们能够看出，在相同的切削速度的条件下，增加磨损标准和对KC313和KC732使用冷却液都可以提高工具的使用寿命。然而，对于KC5010来说提高磨损标准和降低使用冷却液对提高KC5010工具寿命有好处。冷却乳液的这种抑制作用和对磨损机构的效果我们把它列入到了第五章。以及其他类型的磨损也将插入到那里研究。金属的切削研究主要集中在刀具的磨损、刀具的寿命和磨损机理。不过,未来的研究应该更加关注其他因素的影响:l 通过工厂体系建立磨损标准，基本的刀具磨损开端取决于工厂的产品。l 使用刀具的类型，向碳素钢刀具和高速切削刀具。这对于研究在干和湿的条件下研究影响刀具寿命的因素常数（C，n）是有用的。这将提高刀具的寿命，因为它也将影响到切削的经济性24。为了确定切削液在选择磨损标准时所起的作用,不同的磨损标准和经常的进给成本在HMS下必须被研究。不同切削标准的刀具寿命常数在表（1）所列的表格中被摘录和划分。从图7。图8、图9的常数（C，n）的价值在表1和表2中被反映出来。在以后的图中说明这些参数和磨损标准的关系。图10描述了n和磨损标准的关系。当提高n时磨损标准的变化。图1(a)以Log（T）和Log(V)为坐标在不同的磨损标准的情况下所做的图形（干条件）图2 (b)以Log（T）和Log(V)为坐标在不同的磨损标准的情况下所做的图形（湿条件）图2 KC313在不同的磨损标准下由时间（T）和速度（V）为坐标所做的图形（a）以Log（T）和Log(V)为坐标在不同的磨损标准的情况下所做的图形（干条件）(b) 以Log（T）和Log(V)为坐标在不同的磨损标准的情况下所做的图形（湿条件）图3(a)以Log（T）和Log(V)为坐标在不同的磨损标准的情况下所做的图形（干条件）图4(b)以Log（T）和Log(V)为坐标在不同的磨损标准的情况下所做的图形（湿条件）图3-9 KC732在不同的磨损标准下由时间（T）和速度（V）为坐标所做的图形（a）以Log（T）和Log(V)为坐标在不同的磨损标准的情况下所做的图形（干条件）(b) 以Log（T）和Log(V)为坐标在不同的磨损标准的情况下所做的图形（湿条件）图5（a） 以Log（T）和Log(V)为坐标在不同的磨损标准的情况下所做的图形（干条件）图6(b)以Log（T）和Log(V)为坐标在不同的磨损标准的情况下所做的图形（湿条件）图3 KC5010在不同的磨损标准下由时间（T）和速度（V）为坐标所做的图形 （a）以Log（T）和Log(V)为坐标在不同的磨损标准的情况下所做的图形（干条件） (b) 以Log（T）和Log(V)为坐标在不同的磨损标准的情况下所做的图形（湿条件）表1 刀具寿命常数的范围划分RangeCutting InsertCondition0 LogT 2.6KC313Dry0 Log T 4.1KC313Wet0 LogT 2.6KC5010Dry0 Log T 1.75KC5010Wet0 LogT 2.1KC732Dry0 Log T 2.4KC732Wet表2 在三种刀具材料下由C和n所做的磨损标准图（干条件下）WearCriteria(mm)KC 313KC 5010KC732CnCnCnconstantconstantconstantconstantconstantconstant0.151420.2605180.2486300.2880.21650.2125600.2649640.3640.251960.2405960.27810990.3710.32380.2936050.27912330.3930.352500.2756120.27913990.4210.42630.2816250.28115030.4340.452820.2926250.27815170.4340.52920.2946300.27615770.4420.553020.2966320.27415920.4430.63130.3006380.27416110.444表3 在三种刀具材料下由C和n所做的磨损标准图（湿条件下）KC 313KC 5010KC732Wear criterion(mm)CnCnCn0.151670.2014970.298881.0500.3320.21870.2106190.3101051.960.3530.252280.2406100.3121297.180.39300.32440.2506280.3091545.250.42400.352670.2606260.3001782.380.45400.42910.2806190.2901918.670.46800.453380.3106150.2822137.960.49100.53030.3106160.279 2477.420.52400.553970.3406180.2782837.920.55400.64220.3506260.2793243.390.5830在这两种条件下价值能够得到提高，另外，湿润条件n的价值要比干燥条件n的价值低，直到磨损标准达到0.38以后，干燥条件的n开始大于湿润条件的 n。图3-11B可以看出C在磨损标准所做的图形中，在干和湿的条件下磨损标准提高时 C也随之提高。然而，湿的条件下C的价值要比干的条件下高。这证明在整个切削过程中通过使用冷却液提高刀具的寿命和提高磨损标准都可以一直的保护切削刀具材料。接下来，图3-12A描述了KC732材料在干和湿的条件下n与磨损标准之间的关系。磨损价值随着n的提高而提高。此外，湿曲线要比干曲线高。图3-12B描述的一个常数C和磨损价值的比例关系。然而，湿条件的C曲线比干条件下的曲线高，这表面对于材料KC732来说使用冷却液是有益处的。更为重要的这有利于提高磨损标准。C的价值越高，刀具的使用寿命也就变的越高。图3-13A表明冷却液对刀具性能的影响。因此。n越高，刀具的使用寿命就越低。图3-13B可以看出通过使用冷却液和提高磨损价值可以降低C，这说明刀具在湿润的条件下，刀具的使用寿命比较短。之前研究的都是材料KC313和材料KC732，提高n就意味着刀具的寿命将被缩短。然而。大幅度的提高湿曲线C超过干曲线C的补偿下降，KC313和KC732的使用寿命将延长。与次相反。KC5010对此正好相反。图3-14A和图3-14B是没有被碳包裹的情况（KC313）。他表面了在干和湿的切削条件下不同磨损标准的切削速度的价值的关系。图7（a） n与磨损标准为坐标建立的关系图（干和湿条件下）图8（b） C与磨损标准为坐标建立的关系图（干和湿条件下）图3-11 KC313的以泰勒常数与磨损标准为坐标建立的关系图（a）n与磨损标准为坐标建立的关系图（干和湿条件下）(b) C与磨损标准为坐标建立的关系图（干和湿条件下）图9(a) n与磨损标准为坐标建立的关系图（干和湿条件下）图10(b) C与磨损标准为坐标建立的关系图（干和湿条件下）图3-12 KC732的以泰勒常数与磨损标准为坐标建立的关系图（a）n与磨损标准为坐标建立的关系图（干和湿条件下）(b) C与磨损标准为坐标建立的关系图（干和湿条件下） 图11(a) n与磨损标准为坐标建立的关系图（干和湿条件下）图12(b)C与磨损标准为坐标建立的关系图（干和湿条件下）图3-13 KC5010的以泰勒常数与磨损标准为坐标建立的关系图（a）n与磨损标准为坐标建立的关系图（干和湿条件下）(b) C与磨损标准为坐标建立的关系图（干和湿条件下）.这两个条件表明当磨损标准增加的同时机床的成本下降。尽管如此，当成本增加的速度达到再增加就叨叨最佳时。图3-15A和图3-15B是由磨损标准在（0.4-0.6毫米）时，干和湿条件下经济性的比较。干切削的最佳切削速度是90米/分而湿切削的最佳切削速度是120米/分。在图3-16A和图3-16B中列出了在干和湿的条件下含有KC732涂层的速度与成本的函数关系。再次，当磨损标准增加的时候，成本下降。此外，干切削的最佳切削速度是260米/分，而湿切削的最佳切削速度是360米/分。这表面冷却液对这种材料很重要，它不仅可以降低成本，而且还可以提高生产率。图3-17A和图3-17B概括了在干和湿的条件下，对涂有TIALN的材料KC5010的切削速度和成本之间的关系。当切削速度提高时，切削成本也随之提高，当磨损标准提高，切削成本下降。在这两种切削条件下，最佳的切削成本是在速度最低达到210米/分的时候。图3-18A和图3-18B描述的是在不同的磨损标准和不同的切削条件下KC732和KC5010的切削成本的比较。它可以明确地反映出对于KC732来说，冷却液可以延长刀具的寿命。切削速度从260米/分到360米/分为最佳的切削速度。不过，对于KC5010来说在高速加工的情况下冷却液可以使它的刀具寿命降低而且使切削成本提高。从上面这些数据可以看出对于KC732来说，在速度为210米/分-310米/分的速度范围内干切削要比湿切削的经济效率高。当速度达到310米/分是效率最高。对于切削材料KC5010来说在干条件下速度为210米/分时切削成本有效。因此，不管KC732的成本，它的磨损都远远的超过没有处理的KC313和KC5010。表3-10总结了干和湿条件下的最佳切削速度和最佳的切削成本。图3-19A和图3-19B列出的是没有经过处理的KC313在干和湿的条件下，不同的切削速度下切削成本和磨损标准之间的关系。图3-20A和图3-20B列出了处理后的KC732在干和湿的条件下的磨损标准函数。图3-21A和图3-21B列除了KC5010在干和湿的条件下的磨损标准函数。曲线表面在切削速度相同的条件下，增加磨损标准，切削成本下降。在图3-22A表明在湿的条件下改变KC313的性能要比在干的条件下改变其性能使刀具的寿命降低。在图3-22B可以看出KC732和KC5010经过表面处理后的结果和侧面的磨损情况。这清楚的表明在湿润的条件下KC372表面涂TIN-TICN-TIN要比在干的条件下效果明显。在湿的条件下对KC5010表面涂TIALN会减少它的刀具寿命。最后，KC732在所有条件下它的切削性能都要远远的超过KC5010。图13(a) 在不同磨损标准下，切削速度与成本的关系图干切削条件下）图14(b
