课题任务书

课题名称轴端挡圈落料、冲孔、冲槽连续模设计

内容及任务

设计图纸

模具总装图一张

全部模具零件图纸（其中至少有一张电脑绘图）

所有图纸折合成0号图不得少于3张。

设计说明书

1、资料数据充分，并标明数据出处。

2、计算过程详细、完全。

3、公式的字母含义应标明，有时还应标注公式的出处。

4、内容条理清楚，按步骤书写。

5、说明书要求用计算机打印。

6、设计说明书按要求格式独立撰写，不少于12000字。

自选一个重要模具零件编制加工工艺路线，进行相关的计算，并编制加工工艺卡和工序卡。

翻译一篇本专业外文文献（10000个以上印刷符号），并附译文。

拟达到的要求或技术指标1、保证规定的生产率和高质量的冲压件的同时，力求成本低、模具寿命长。

2、设计的冷冲模必须保证操作安全、方便。

3、冲模零件必须具有良好的工艺性，即制造装配容易、便于管理。

4、便于搬运、安装、紧固到冲床上并且方便、可靠。

5、保证模具强度前提下，注意外形美观，各部分比例协调。


进度安排起止日期工作内容备注

第2～5周（2.28~3.27）毕业调研及实习、搜集设计的相关资料

第6周（3.28~4.3）根据工件形状，确定工艺方案及模具结构型式

第7~8周（4.4~4.17）进行主要参数计算，画出模具装配结构草图

第9~10周（4.18~5.1）绘制模具总装配图

第11~12周（5.2~5.15）绘制模具各零件图

第13周（5.16~5.22）编制主要模具零件的加工工艺路线和工序卡

第14~15周（5.23~6.5）整理设计说明书、打印图纸资料，申请答辩

第16周（6.6~6.10）毕业答辩

主要参考资料１、《冷冲压工艺及模具设计》刘心治主编重庆大学出版社

２、《冲压工艺及模具设计》万战胜主编 铁道出版社

３、《冲模设计》 吉林人民出版社

４、《实用冲压技术》 机工出版社

５、《冷冲压及塑料成型工艺与模具设计资料》 机工出版社

６、《模具设计与制造简明手册》 冯炳尧等编 上海出版社

7、《冲压工艺模具设计实用技术》　郑家贤编　机械工业出版社

8、《实用板金冲压工艺图集》　梁炳文主编　机械工业出版社

9、《几何量公差与检测》甘永立主编　上海科学技术出版社

10、《机械制造专业英语》章跃主编　机械工业出版社


内容简介：
