拖拉机动力输出总成的设计（720转-分）【优秀拖拉机动力课程毕业设计含3张CAD图纸】.rar

毕业设计（论文）封皮.doc---(点击预览)

摘要.doc---(点击预览)

拖拉机动力输出总成的设计（720转-分）.doc---(点击预览)

开题报告.doc---(点击预览)

动力输出轴--文献翻译.doc---(点击预览)

大齿轮.dwg

装配图.dwg

高速轴.dwg

压缩包内文档预览：

编号：474897 类型：共享资源大小：485.96KB 格式：RAR 上传时间：2015-08-28 上传人：QQ14****9609 IP属地：陕西

40
积分

版权申诉 word格式文档无特别注明外均可编辑修改；预览文档经过压缩，下载后原文更清晰！ 立即下载

关键词：: 动力输出总成汽车设计课程毕业设计拖拉机动力输出总成的设计

资源描述：

动力输出总成的设计（720转-分）

拖拉机动力输出总成的设计（720转-分）【优秀拖拉机动力课程毕业设计含3张CAD图纸】

【带开题报告+外文翻译】【44页@正文14000字】【详情如下】【需要咨询购买全套设计请加QQ1459919609】

动力输出轴--文献翻译.doc

封皮.doc

开题报告.doc

拖拉机动力输出总成的设计（720转-分）.doc

摘要.doc

装配图.dwg

大齿轮.dwg

高速轴.dwg

动力输出总成的设计（720转/分）

摘要

动力输出轴是拖拉机的重要工作部件,动力输出主要用于拖拉机在行进中输出发动机动力以驱动农机具,如割草机、喷药机等。动力输出总成的设计是基于减速增扭的原理。动力从变速箱引出，再进过一对大小齿轮减速，转速减小的同时，扭矩成比例的增加。动力输出没有标准的设计过程，主要根据变速器和减速器的设计，确定齿轮的传动类型、传动关系、受力分析、建立数学模型。依据传统的设计方法，本着半经验半理论的设计原则通过类比的方法，参考已有车型的动力输出的设计过程，然后验算零件的强度和机械应力情况，最后确定了采用半独立式的动力输出机构方案，动力直接从发动机的曲轴引出，这种输出类型现在被广泛使用，特别受到欧美的青睐。本次设计采用的主动的直齿滑动齿轮啮合，主动齿轮可以在高速轴上滑动，以提供啮合和分离的选择。这种设计最大的优点是结构简单，便于安装和维修。

而且为了避免动力输出轴头在高速旋转下危及人身的事故发生，本次设计专门设计了动力输出轴保护罩，保证外露的高速旋转部件不会伤害人，提高了使用的安全性。

关键词：动力输出轴，半独立式，主动齿轮，从动齿轮

POWER TAKEOFF SHAFT DESIGN（720r/min）

ABSTRACT

Power take off shaft is an important part of the tractor, PTO shaft provides a means to drive the machines that are being towed by the tractor, Take mower and manure spreaders for example.

The PTO shaft operates on the principle of reducing the PTO shaft speed, before the drive from the transmission is applied. At the same time ,the PTO shaft increases the torque ,for when speed is lost through gears, torque is gained in the same proportion . According to the design of the transmissions in consideration of the simplicity and reliability. According to the traditional mean of design, part experience and theory and analogism. We firstly chose gear type, make selection of the gear parameter, then establish the mathematic model dose the type of the being.

In this thesis, we dose semi-independent type. This type of PTO shaft is popular not only in our country, but also in Europe. The merit of this type is outstanding, We choose spur gear to transmit the drive.the driving gear can be slid along the splines on the internal end of shaft and into mesh with driven gear. The means of this type is easy for fixing and mending.

To avoid the accident of the wound from the revolving of the end of PTO shaft, the shaft and universal joint of PTO should be guarded by commercially available shields ,which cover moving part, so it will improve the softy.

Key words：PTO shaft, semi-independent, driving gear, driven gear

第一章绪论........ .. .. .. .. .. ........................1

§1.1拖拉机发展概述............................1

§1.2动力输出总成的概述............................3

§1.3拖拉机工作速度匹配...........................5

§1.4 动力输出轴的转速配置...........................5

§1.5动力输出轴性能...........................6

第二章动力输出总成齿轮主要参数的确定... .. .. .. .. .....8

§2.1 齿轮的概述.... .. .. .. .. .......................8

§2.2 方案一设计.. .. ................................8

§2.2.1 方案一齿轮计算 . ................... ......8

§2.2.2 方案一轴设计......................... .....9

§2.3 方案二设计.. ............... .. ...............12

§2.3.1 方案二齿轮设计...................... ......12

§2.3.2 齿轮变位设计...................... ........ 15

§2.3.3 齿轮重合度的设计...................... ....17

第三章动力输出总成轴承的计算......................19

§3.1 轴承的概述.. .. .. .. ...........................19

§3.2 轴承的计算.................................19

第四章轴的校核计算................................21

§4.1 高速轴设计.... .. .. .. .........................21

§4.2 低速轴设计.... .. ..............................23

第五章花键的计算...................................26

§5.1 低速轴花键设计. ... ............................26

§5.2 高速轴花键设计.................................27

§5.3 连轴器花键设计........................ ........ 28

第六章控制机构设计.................................30

§6.1 自锁弹簧的设计.... .. .........................30

§6.2 操纵机构位置的设计.............................31

第七章动力输出轴的加工方法.......................34

第八章使用与保养......................35

第九章结论.........................................37

参考文献...............................................38

致谢...................................................40

第一章绪论

§1.1 拖拉机发展概述

　国外拖拉机的技术发展趋势，是广泛采用高新技术，提高拖拉机性能、可靠性、操作方便性、舒适性、安全性及外观质量等。

　　1、降低振动、噪声及发动机排放污染

　　拖拉机前驱动桥采用液压悬架，以大幅度降低拖拉机的振动；小型拖拉机采用小缸径柴油机代替单缸柴油机，使柴油机结构尺寸缩小、噪声降低。此外，发达国家还对拖拉机发动机的排放规定了严格的标准，并分期实施。

　　2、完善性能，满足农田与运输作业要求

　　如完善拖拉机的传动系统，采用先进的换挡装置，满足农机具不同作业速度需要；采用前后桥驱动与制动、前后动力输出轴以及可变速的后动力输出轴，以适应配置不同农具的动力配套需要；另外，静液压驱动的拖拉机也日趋增多。

　　3、提高可靠性

　　如将拖拉机平均故障时间(MTBF)提高到300h以上；广泛采用子午线轮胎，大中型拖拉机普遍应用宽断面子午线轮胎，较大地提高拖拉机的附着性能和耐磨性能；完善液压悬挂系统，提高农机具悬挂的方便性。在大中型拖拉机上广泛采用负荷传感的闭环液压控制系统、电子液压悬挂系统；将液压力输出增至3-4组，每组单独操作；拖拉机设置前、后三点悬挂，普遍采用快速挂接装置等。

参考文献

[1] 程悦荪.拖拉机设计.北京：中国农业机械出版社，1981,43-67

[2] 吉林工业大学拖拉机教研室编.拖拉机构造.北京：机械工业出版社，1974,90-99

[3] 文农.底盘设计.北京：机械工业出版社，1981.67-89

[4] 《拖拉机编辑部》.拖拉机设计和计算.上海：上海科学技术文献出版社,45-67

[5] 孙恒模主编.机械原理（第六版）.北京：高等教育出版社，2001,67-87

[6] 濮良贵、纪名刚.机械设计（第七版）北京：高等教育出版社，2001, 184-234

[7] 林建兴，曹曼玲,刘鸿文.简明材料力学.北京：高等教育出版社，1995，67-90

[8] 第一机械工业部机械研究院农业机械研究所编.农业机械设计手册.北京：机械工业出版社，1973，12-67

[9] 侯洪生.机械工程图学.北京：科学出版社，2003，67-120

[10] 全国拖拉机标准化技术委员会秘书处，中国一拖集团有限公司，洛阳拖拉机研究所编.拖拉机柴油机设计标准手册.北京：中国标准化出版社，45-70

[11] 吉林工业大学，北京农机学院，洛阳农机学院，湖北农机学院，镇江农机学院，河北工学院合编.拖拉机底盘结构设计图册.北京：机械工业出版社，67-90

[12] 东北大学《机械零件设计手册》编写组编，蔡春源主编.机械零件设计手册，1145-1340

[13] 机械电子工业部洛阳拖拉机研究所主编.拖拉机设计手册.北京：机械工业出版社，1994.

45-87

[14] 王昆，何小柏，汪信远.机械设计机械设计基础课程设计.北京：高等教育出版社，2005，119-197

[15] 姜勇.AUTO CAD 高级教程 .北京：人民邮电出版社，1994，8-70
