工作台和油箱底座119.dwg

控制柜门119.dwg

液压台钻电路图.dwg

电路1.dwg

立柱119.dwg

压缩包内文档预览：(预览前20页/共30页)

编号：516004 类型：共享资源大小：906.08KB 格式：RAR 上传时间：2015-11-12 上传人：QQ14****9609 IP属地：陕西

40
积分

版权申诉 word格式文档无特别注明外均可编辑修改；预览文档经过压缩，下载后原文更清晰！ 立即下载

关键词：: 台式钻床改造设计液压设计台式钻床的改造设计液压台式钻床改造设计

资源描述：

台式钻床的改造设计

液压台式钻床的设计全套课程毕业设计

台式钻床的改造设计【优秀液压台式钻床改造设计含5张CAD图纸】

【带开题报告+申报表】【42页@正文15800字】【详情如下】【需要咨询购买全套设计请加QQ1459919609】.bat

副本开题报告.doc

封面.doc

小论文

工作台和油箱底座119.dwg

开题报告 (2).doc

开题报告.doc

控制柜门119.dwg

液压台钻电路图.dwg

申报表背面.doc

电路1.dwg

立柱119.dwg

论文-ok.doc

论文.doc

摘要

本文主要介绍了台式钻床的改造和设计，通过导入液压进给系统和PLC控制系统将台式钻床改造为自动钻床，并可通过PLC实现自动控制。该钻床在钻削过程中可以用液压油缸来实现自动进给和快速退回；主运动可以由液压马达来实现。本设计采用设计方法有：传统的设计方法与现代研究方法相结合；计算机辅助设计；模块化设计等。液压台钻设计的主要特点：

1、考虑到液压台式钻床的使用环境及工况特点，从结构紧凑、加工及制造简单、使用和维护安全方便、经济性好等方面着手，将总设计分为液压系统、电气控制系统和机械传动系统三大模块来进行；在整体布局上分为上装和下装两大部分。

2、为了减少布局空间，将台钻下装部分设计成箱体控制柜的形式，底座油箱置于下层，上层为液压及电气集成控制区，将驱动电机用联接法兰联成一体，将所有的液压控制阀集成安装在一个大的阀块体上，大大减小了台钻的整体布局。

3、本设计在可以实现在钻孔加工时的自动进给和快退；钻孔深度半自动控制及速度显示装置，在很大程度上减轻了劳动强度，提高生产效率。

4、由于液压传动技术和电气控制技术的诸多特点，在元件的选择、设计上突显其优越性，大大降低了生产成本。

关键词: 模块化设计;联接法兰;集成控制

Abstract

This thesis mainly illustrates the improving and design of Bench-type drilling machine. The drill press can be move forward automatically and downward fleetly by the hydraulic oil jar. Hydraulic motor can achieve the central locomotion. The first mean of my graduation design integrate the traditional design and modern design commutatively, the second is CAD, and the third is the design of modularity, and so on. The characteristic of the design of the hydraulic pressure drill shows as follows:

1.Considering the working characteristic of the hydraulic pressure drill press, I take measures at the aspects of the compact configuration ,making simple, using conveniently、 maintenance safely and economic. I divide it into three module .They are hydraulic pressure system, electrical control system and machine drive system. Seeing form the whole layout, I divide it into upside chest and base chest.

2. For reducing the room, I design the base chest into the form of the control tank. The pedestal oil box located the under layer, the super stratum is the integration control area of the hydraulic pressure and electrical control. Join the drive electromotor with the hydraulic pressure pump by the link flange .All the hydraulic pressure control clique install on the assemble piece. It will reduce the collectivity area.

3. The design can realize downwards and forward movement automatically and fleetly. Bore deepness semiautomatic control equipment, velocity display device reduce the worker’s laboring intensity, increase productivity consumedly.

4. Because of the characteristics of the hydraulic pressure system and electrical control system, they display the advantage of the selection of the element and whole design, and reduce the produce cost consumedly.

Key words: the design of module; link flange; integration control

摘要

Abstract

第1章引言

1.1.1金属切削机床国内现状┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈3

1.1.2液压传动技术在金属切削机床中的应用与发展┈┈┈┈┈┈┈┈┈┈┈┈┈┈3

1.1.3钻削机床┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈8

1.2.1本毕业设计的研究意义和内容安排┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈9

1.2.2设计研究的意义┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈9

1.2.3本论文的内容安排┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈10

第2章液压台式钻床设计

2.1整体方案的设计与选择┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈11

2.2液压传动系统的设计┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈13

2.2.1液压传动系统的设计要求┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈13

2.2.2分析液压系统的工况┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈13

2.2.3液压油缸(实现上下进给进动)的设计┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈14

2.2.4液压马达(实现主轴的旋转)的设计与选用┈┈┈┈┈┈┈┈┈┈┈┈┈┈17

2.2.5拟定液压系统的原理图┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈20

2.2.6液压油泵的设计及液压元件的选择┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈20

2.2.7液压系统性能的验算┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈24

2.2.8液压系统工作介质的选择┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈24

2.3电气控制系统的设计 ┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈25

2.3.1电气控制系统的设计要求 ┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈25

2.3.2电气控制系统的设计 ┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈26

2.3.3选择电气元件 ┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈27

2.3.4制定电气元件明细表 ┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈29

第3章机械传动部分的设计 ┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈29

3.1底座油箱及工作台的设计┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈29

3.2 立柱组件的设计 ┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈31

3.3 悬臂组件的设计 ┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈32

3.4 进给油缸组件的设计 ┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈34

3.5 液压马达及钻夹头组件设计 ┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈35

3.6 钻孔深度控制装置的设计 ┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈36

3.7钻床主轴转速的显示装置的设计 ┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈37

总结 ┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈39

参考文献 ┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈41

致谢┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈┈42

第1章引言

1.1.1金属切削机床国内发展现状

（1）金属切削机床在国民经济中的地位

金属切削机床是用切削的方法将金属毛坯加工成机器零件的机器，它是制造机器的机器，所以有“工作母机”之称。在现代机械制造工业中，加工机器零件的方法多种多样，如铸造、锻造、焊接、切削加工和各种加工等。切削加工是将金属毛坯加工成具有较高精度的形状、尺寸和较高表面质量零件的主要加工方法。在加工精密零件时，目前主要还是依靠切削加工来达到所需的加工精度和表面质量。因此，金属切削机床是机器零件的主要设备。它所担负的工作量，约占机器总制造工作量的40% ~ 60%。所以机床的技术水平直接影响机械制造工业的产品质量和劳动生产率。

参考文献

[1]王懋瑶. 液压传动与控制教程[M].天津: 天津大学出版社,1999.

[2]徐灏. 机械设计手册第二版第五卷[M].北京:机械工业出版社,2000.

[3]张维纪. 金属切削原理及刀具[M].浙江:浙江大学出版社,2002.

[4]齐占庆. 机床电气控制技术第三版[M].北京:机械工业出版社,1999.

[5]戴曙. 金属切削机床[M].北京: 机械工业出版社,2005.

[6]濮良贵.纪名刚.机械设计第七版[M].北京:高等教育出版社,2004.

[7]大连理工大学工程画教研室.机械制图[M]. 北京:高等教育出版社,2002.

[8]北京科技大学，东北大学．工程力学[M]．北京：高等教育出版社，1997: 25-40, 87, 150-160.

[9]吴常德.计算机绘图实例导航Auto CAD2000[M]．北京：机械工业出版社，2002.

[10]周士昌. 液压气动系统设计运行禁忌470例[M].北京: 机械工业出版社,2002.





内容简介：: 台式钻床的改造和设计目前，我国中、小型企业的产品质量和生产效率都需要有一个新的提高但是加工手段却远远不能满足需要许多中小型企业都结合自己的实际对设备的技术状态进行改进，通过强化自身以求自我发展 .普通钻床为单轴机床，但安装上多轴箱就会成为多轴的钻床，改造成多轴钻床后，能大大地缩短加工时间，提高生产效率。多轴加工应用：据统计，一般在车间中普通机床的平均切削时间很少超过全部工作时间的 15%。其余时间是看图、装卸工件、调换刀具、操作机床、测量以及清除铁屑等等。使用数控机床虽然能提高 85%，但购置费用大。某些情况下，即使生产率高，但加工相同的零件，其成本不一定比普通机床低。故必须更多地缩短加工时间。不同的加工方法有不同的特点，就钻削加工而言，多轴加工是一种通过少量投资来提高生产率的有效措施。多轴加工优势：虽然不可调式多轴头在自动线中早有应用，但只局限于大批量生产。即使采用可调式多轴头扩大了使用范围，仍然远不能满足批量小、孔型复杂的要求。尤其随着工业的发展，大型复杂的多轴加工更是引人注目。例如原子能发电站中大型冷凝器水冷壁管板有 15000 个 20 孔，若以摇臂钻床加工，单单钻孔与锪沉头孔就要 842.5 小时，另外nts 1 还要划线工时 151.1 小时。但若以数控八轴落地钻床加工，钻锪孔只要 171.6 小时，划线也简单，只要 1.9 小时。因此，利用数控控制的二个坐标轴，使刀具正确地对准加工位置，结合多轴加工不但可以扩大加工范围，而且在提高精度的基础上还能大大地提高工效，迅速地制造出原来不易加工的零件。有人分析大型高速柴油机 30 种箱形与杆形零件的 2000多个钻孔操作中，有 40%可以在自动更换主轴箱机床中用二轴、三轴或四轴多轴头加工，平均可减少 20%的加工时间。 1975 年法国巴黎机床展览会也反映了多轴加工的使用愈来愈多这一趋势。多轴加工的设备：多轴加工是在一次进给中同时加工许多孔或同时在许多相同或不同工件上各加工一个孔。这不仅缩短切削时间，提高精度，减少装夹或定位时间，并且在数控机床中不必计算坐标，减少字块数而简化编程。它可以采用以下一些设备进行加工：立钻或摇臂钻上装多轴头、多轴钻床、多轴组合机床心及自动更换主轴箱机床。甚至可以通过二个能自动调节轴距的主轴或多轴箱，结合数控工作台纵横二个方向的运动，加工各种圆形或椭圆形孔组的一个或几个工序。现在就这方面的现状作一简介。多轴头：从传动方式来说主要有齿轮传动与万向联轴节传动二种。这是大家所熟悉的。前者效率较高，结构简单，后者易于调整轴距。从结构来说有不可调式与可调式二种。前者nts轮辐六轴专用钻床 2 轴距不能改变，多采用齿轮传动，仅适用于大批量生产。为了扩大其赞许适应性，发展了可调式多轴头，在一定范围内可调整轴距。它主要装在有万向 .二种。（ 1）万向轴式也有二种 :具有对准装置的主轴。主轴装在可调支架中，而可调支架能在壳体的 T 形槽中移动，并能在对准的位置以螺栓固定。（ 2）具有公差的圆柱形主轴套。主轴套固定在与式件孔型相同的模板中。前一种适用于批量小且孔组是规则分布的工件（如孔组分布在不同直径的圆周上）。后一种适用于批量较大式中小批量的轮番生产中，刚性较好，孔距精度亦高，但不同孔型需要不同的模板。多轴头可以装在立钻式摇臂钻床上，按钻床本身所具有的各种功能进行工作。这种多轴加工方法，由于钻孔效率、加工范围及精度的关系，使用范围有限。多轴箱：也象多轴头那样作为标准部件生产。美国 Secto 公司标准齿轮箱、多轴箱等设计的不可调式多轴箱。有 32 种规格，加工面积从 300 300 毫米到 600 1050 毫米，工作轴达 60 根，动力达 22.5 千瓦。 Romai 工厂生产的可调多轴箱调整方便，只要先把齿轮调整到接近孔型的位置，然后把与它联接的可调轴移动到正确的位置。因此，这种结构只要改变模板，就能在一定范围内容易地改变孔型，并且可以达到比普通多轴箱更小的孔距。根据成组加工原理使用多轴箱或多轴头的组合机床很适用nts 3 于大中批量生产。为了在加工中获得良好的效果，必需考虑以下数点：（ 1）工件装夹简单，有足够的冷却液冲走铁屑。（ 2）夹具刚性好，加工时不形变，分度定位正确。（ 3）使用二组刀具的可能性，以便一组使用，另一组刃磨与调整，从而缩短换刀停机时间。（ 4）使用优质刀具，监视刀具是否变钝，钻头要机磨。（ 5）尺寸超差时能立即发现。多轴钻床：这是一种能满足多轴加工要求的钻床。诸如导向、功率、进给、转速与加工范围等。巴黎展览会中展出的多轴钻床多具液压进给。其整个工作循坏如快进、工进与清除铁屑等都是自动进行。值得注意的是，多数具有单独的变速机构，这样可以适应某一组孔中不同孔径的加工需要。 1.2.4 自动更换主轴箱机床为了中小批量生产合理化的需要，最近几年发展了自动更换主轴箱组合机床。 (1) 自动更换主轴机床自动更换主轴机床顶部是回转式主轴箱库，挂有多个不可调主轴箱。纵横配线盘予先编好工作程序，使相应的主轴箱进入加工工位，定位紧并与动力联接，然后装有工件的工作台转动到主轴箱下面，向上移动进行加工。当变更加工对象时，只要调换悬挂的主轴箱，就能适应不同孔型与不同工序的需要。 (2) 多轴转塔机床 nts轮辐六轴专用钻床 4 转塔上装置多个不可调或万向联轴节主轴箱，转塔能自动转位，并对夹紧在回转工作台的工件作进给运动。通过工作台回转，可以加工工件的多个面。因为转塔不宜过大，故它的工位数一般不超过 4 6 个。且主轴箱也不宜过大。当加工对象的工序较多、尺寸较大时，就不如自动更换主轴箱机床合适，但它的结构简单。 (3) 自动更换主轴箱组合机床它由自动线或组合机床中的标准部件组成。不可调多轴箱与动力箱按置在水平底座上，主轴箱库转动时整个装置紧固在进给系统的溜板上。主轴箱库转动与进给动作都按标准子程序工作。换主轴箱时间为几秒钟。工件夹紧于液压分度回转工作台，以便加工工件的各个面。好果回转工作台配以卸料装置，就能合流水生产自动化。在可变生产系统中采用这种装置，并配以相应的控制器可以获得完整的加工系统。 (4) 数控八轴落地钻床大型冷凝器的水冷壁管板的孔多达 15000 个，它与支撑板联接在一起加工。孔径为 20 毫米，孔深 180 毫米。采用具有内冷却管道的麻花钻， 5 7 巴压力的冷却液可直接进入切削区，有利于排屑。钻尖磨成 90供自动定心。它比普通麻花钻耐用，且进给量大。为了缩短加工时间，以 8 轴数控落地加工。 nts 5 多轴加工趋势：多轴加工生产效率高，投资少，生产准备周期短，产品改型时设备损失少。而且随着我国数控技术的发展，多轴加工的范围一定会愈来愈广，加工效率也会不断提高。生产任务：在一批铸铁连接件上有同一个面上有多个孔加工。在普通立式钻床上进行孔加工，通常是一个孔一个孔的钻削，生产效率低，用非标设备，即组合机床加工，生产效率高，但设备投资大。但把一批普通立式普通单轴钻床改造为立式多轴钻床，改造后的多轴钻床，可以同时完成多个孔的钻、扩、铰、等工序。 General transformation of multi-axis drilling machine drilling machin At present, Chinas small and medium enterprises in product quality and production efficiency are the need for a new increase. But the processing means is far from sufficient. Many small and medium enterprises with their actual technical state nts轮辐六轴专用钻床 6 of equipment improvements, through strengthening its own. In order to self-development.Common drilling for single-axis machine tools, but the installation will become a multi-axis multi-axle box of the drill, transformation into a multi-axis drilling, we could greatly shorten the processing time, improve production efficiency. Application of multi-axis machining ： According to statistics, in general machine tools in the workshop in general, the average cutting time rarely exceeds 15% of total working hours. The remaining time is plug-in, loading and unloading the workpiece, exchange tools, operation tools, measurements, and clear the iron filings and so forth. Although the use of CNC machine tools can improve 85%, but the purchase of costly. In some cases, even if the high productivity, but the processing of the same components, the cost is not necessarily lower than the average machine. Therefore must be more to shorten the processing time. Different processing methods have different characteristics, the drilling process, the multi-axis machining is a small investment to increase productivity through effective nts 7 measures. The advantages of multi-axis machining ： Although it is not the first in automatic multi-axis adjustable long line applications, but only limited to high-volume production. Even with the adjustable multi-axis head expanded the scope of use is still far from being able to meet the volume is small, hole complex requirements. In particular, as industrial development, large and complex multi-axis machining is even more compelling. For example, large-scale nuclear power plants in the water-wall tube plate condenser has 15000 20 holes, if radial drilling machine processing, and simply drilling holes and countersink countersunk head is necessary to 842.5 hours, while also crossed hours 151.1 hours. However, if the 8-axis CNC machining floor drilling, drilling countersink holes as long as 171.6 hours, crossed is also simple, as long as 1.9 hours. Therefore, the use of numerical control of two axis, so that proper alignment tool processing location, combined with multi-axis machining can not only expand the range of processing, but also on the basis of improving the accuracy can greatly enhance the work nts轮辐六轴专用钻床 8 efficiency, easy to quickly create original processing parts. Some analysis of large high-speed diesel engine with 30 kinds of box-shaped rod-shaped parts of the more than 2,000 drilling operations, 40% could be the automatic replacement of machines using two-axis spindle box, three-axis or four-axis multi-axis machining head, the average can be reduced 20% of the processing time. Machine Tool Exhibition in Paris in 1975 also reflected the multi-axis machining using more and more the trend. Multi-axis machining equipment ： Multi-axis machining is the same time in a feed processing a number of holes or simultaneously in many of the same or different processing of a workpiece on each hole. This will not only shorten the cutting time and improve accuracy, reduce fixturing or positioning time, and in the CNC machine tool is not necessary to calculate the coordinates, reducing the number of character blocks and simplified programming. It can be processed using the following equipment: radial drilling vertical drilling, or upload multi-axis head, multi-axis drilling machine, multi-axis modular machine tool nts 9 spindle box heart and automatic replacement of machines. May even be able to automatically adjust wheelbase by two or more of the spindle axle box, junction All CNC vertical and horizontal table two directions of movement, processing a variety of round or oval-shaped hole group of one or several steps. Now the status quo in this regard to make a profile. Multi-Axis Head ： Transmission is from the main drive gear drive with two kinds of universal joint couplings. This is our familiar. Former is more efficient, simple structure, which is easy to adjust wheelbase. From the structure is concerned there is not adjustable and the adjustable two kinds. The former can not change the wheelbase, multi-use gear drive, only applies to high-volume production. Adaptability in order to expand its approval to develop a multi-axis adjustable head, in a certain range adjustable wheelbase. It is mainly mounted in a universal. Two. (1) there are two kinds of universal axis: alignment device with a spindle. Spindle mounted on adjustable bracket in an adjustable bracket can be T-shaped slot in the shell move, and the position in alignment with bolted. (2) nts轮辐六轴专用钻床 10 with a tolerance of cylindrical spindle units. Set of fixed spindle hole with pieces of the same type template. The former applies to small batch and the rules of distribution of pore groups are artifacts (such as the hole groups in different diameter circle). The latter applies to a larger batch-type production of small quantities of turns, rigid better pitch accuracy is also high, but a different hole requires a different template. Multi-axis head can be mounted on vertical drilling-type radial drilling machine, press the drill itself with the various functions work. This multi-axis processing methods, due to drilling efficiency, range and accuracy of processing of the relationship between the use of limited scope. Multi-axle box ： As also the first multi-axis as the production as a standard component. U.S. Sectos standard gear boxes, multi-axle box, etc. are not designed adjustable multi-axle box. 32 kinds of specifications, process size from 300X300 mm to 600X1050 mm, the working-axis up to 60, and power up to 22.5 kilowatts. Romai factory adjustable multi-axle nts 11 box easy to adjust, as long as the gear should first be adjusted to the location near the pass and then connected with its adjustable-axis move to the correct location. Therefore, this structure changes as long as the template, will be able to pass a certain extent change the content of shoes, and can reach more than ordinary axle box smaller pitch. According to principles of the use of group processing the first multi-axle, or a combination of multi-axis machine tool is applicable to large and medium volume production. In order to process to get good results, need to consider the following points: (1) workpiece clamping simple, there is enough coolant away iron filings. (2) The fixture rigidity, processing, without deformation, dividing the right position. (3) the possibility of using the two group knives for a group to use, another set of grinding and adjustment, thereby reducing tool change downtime. (4) The use of quality tools to monitor whether the blunt tool, drill grinding to machine. (5) Dimensions can be detected immediately when the ultra-poor. Multi-axis drilling machine ： This is a multi-axis nts轮辐六轴专用钻床 12 machining to meet the requirements of the drill. Such as orientation, power, feed, speed and processing range. Displayed at the Paris Exhibition of multi-axis drilling machine with hydraulic multi-feed. Throughout its work, such as fast-forward through the bad, workers enter and clear the iron filings are all automatically. It is noteworthy that the majority of agencies with separate variable speed, so that one group can adapt to the different pore size hole processing needs. 1.2.4 automatic replacement machine tool spindle box In order to rationalize the needs of small and medium volume production in recent years the development of the automatic replacement of modular machine tool spindle box. (1) The automatic replacement spindle machine Automatic replacement of rotary spindle machine tool spindle box at the top is a library, there are several non-adjustable hanging spindle box. Vertical and horizontal patch panel to the first series of good working procedures, so that the corresponding spindle box into the processing station, location and with the power connection tight, and then turn to the table with nts 13 the workpiece spindle box below, upward mobility for processing. When the change processing object, as long as the exchange suspension spindle box, you can pass with different processes for different needs. (2) The multi-axis machine tool turret Turret to install more non-adjustable or universal coupling spindle box, turret can automatically switch to digital, and clamp the workpiece in the rotary table to feed motion. Through the rotary table can be a number of workpiece surface. Because the turret not be too big, so it is generally not exceed the median of workers 4-6. And the spindle box is also not too large. When the machining process more objects, size larger, it should automatically replace the machine tool spindle box fit, but its simple structure. (3) Automatic replacement of modular machine tool spindle box It consists of automatic line or a combination of standard machine parts. Non-adjustable multi-axle box and power box by home base in the horizontal, the spindle rotates, the entire case library fastening device to the system in the slip into the board. Library nts轮辐六轴专用钻床 14 Headstock rotation and feed movement is based on standard routines of work. Headstock time for a few seconds. Clamping the hydraulic sub-degree rotary table so that each workpiece surface. Good fruit rotary table accompanied by discharging device, we can co-flow production automation. In the variable production system using this device, accompanied by the corresponding controller can obtain a complete processing system. (4) 8-axis CNC drill floor Large condenser water wall tube plate holes as many as 15,000, which linked together with the support plate processing. Diameter of 20 mm, hole depth 180 mm. Used inside the cooling pipe has a twist drill ,5-7 bar pressure, coolant directly into the cutting area is conducive to chip removal. And ground into a 90 drill point for the self-centering. Durable than regular twist drill, and a large quantity of feed. To shorten the processing time to 8-axis CNC machining floor. trends in multi-axis machining ： Multi-axis machining high production efficiency, low investment and nts 15 production preparation cycle is short, product modification, when a small loss of equipment. And as Chinas CNC technology, the scope of multi-axis machining will become the broad, processing efficiency will be improved. production tasks ： A group of cast-iron joints have the same surface processing with multiple holes. In the general processing of vertical holes on the drill, usually a hole a hole drilling, production efficiency is low, use non-standard equipment, that is, combination of machining, production efficiency is high, but the large investment in equipment. However, the number of common vertical drilling machine to transform ordinary single-axis vertical multi-axis drilling machine after transformation, multi-axis drilling machine can simultaneously perform multiple hole drilling, expansion, hinges, and other processes. nts轮辐六轴专用钻床 16 nts 1 长春理工大学光电信息学院毕业设计（论文）登记表分院机电工程分院专业机械电子工程班级 09523 学生姓名袁贺晓指导教师张广杰设计（论文）起止日期 2013 年 3 月 2 6 月 21 教研室主任题目名称（包括主要技术参数）及要求 1.题目：台式钻床的改造和设计 2.要求： 1）、液压传动技术是一门新兴的技术，是研究以有压液体为能源介质实现各种机械的传动与控制的学科。由于液压传动技术相对于电气传动、机械传动具有单位功率的重量轻、结构尺寸小、反应速度快及大范围内能实现无级调速且高速性好等特点，它的发展非常迅速，现已广泛应用于机械制造、电子、工程机械、交通运输、军事器械、冶金、宇宙航天、海洋开发等新的技术领域。由于液压传动技术的诸多突出特点，液压技术应用于机电产品制造行业已非常广泛，液压设备在制造行业中占据着相当重要的位置，若将液压技术与传统的钻削设备相结合，将大大减轻钻削机床的重量，减小其结构尺寸，而且能实现无级变速和传递较大的功率。因此，将液压技术应用于钻床设备中对机械加工制造行业和国民经济的发展有着重要的意义。 2）、本毕业设计课题是设计一台液
